ChatGPT reviews Oscilloclocks!

Posted on by

Recently [Nels] wrote in saying he’d been having a nice chat with ChatGPT, and in the course of conversation, he asked this trendy AI tool to write a “review” of the clocks we make here in the Oscilloclock Lab.

Here is the result – verbatim!

[Nels] Write a review of Oscilloclock tube clocks.

[ChatGPT] Oscilloclock tube clocks are a unique and visually stunning way to keep time. These clocks use vintage CRT (cathode ray tube) displays, similar to those used in old televisions and oscilloscopes, to display the time and other information in a mesmerizing way.

One of the standout features of Oscilloclock tube clocks is their attention to detail. These clocks are handmade by a single individual, and every aspect of their construction is carefully considered. From the selection of the CRT displays to the circuitry that drives them, every component is chosen for its quality and durability.

The result of this attention to detail is a clock that not only looks amazing but is also highly reliable and accurate. The timekeeping is controlled by an ultra-precise quartz crystal, ensuring that the clock is always on time. Additionally, the clock can be set to display a variety of other information, such as the date or temperature, making it a versatile addition to any room.

One of the things that sets Oscilloclock tube clocks apart from other timepieces is their ability to be customized. The clock face can be designed to display any number of patterns or shapes, from geometric shapes to more abstract designs. This customization allows the clock to be tailored to the individual’s taste and can even be used to display personalized messages or graphics.

While Oscilloclock tube clocks are undoubtedly a premium product, they are worth every penny for those who appreciate the unique combination of vintage technology and modern craftsmanship. The quality and attention to detail of these clocks are unmatched, and they are sure to be a conversation starter in any room. If you are looking for a truly one-of-a-kind timepiece, the Oscilloclock tube clock is definitely worth considering.

Our thoughts?

While there are three inaccuracies (one incorrect fact and two debatable points), the writeup is a lovely read and initially made your humble Lab technician feel warm inside.

Until, upon objective reflection, I recognised some of the style, phrases and wording!

Well, of course it should look familiar! ChatGPT predicts what the human expects as a response, and then cleverly arranges and regurgitates data that it has absorbed as part of its training. Apparently, it has devoured much of the Internet up until early 2022. This would include 59 blog posts and 19 pages published on Oscilloclock.com up until that date – and a few other references such as three lovely write-ups on Hackaday.

[Nels] apparently did not continue the conversation, but if he had, he could have pointed out the three inaccuracies (Quiz – have you spotted them yet? Check your answers below), and ChatGPT would have learned something.

Even with a rough understanding of how this tool works, it’s amazing to see the outcome.

Crazy idea – what if your Oscilloclock could connect to an AI service and deliver cool new images, funny text, or interesting conversations? Just watch out for mistakes!

Robots wrote this review! Oil paintings generated by ChatGPT sibling DALL·E 2

Quiz answers:

  1. Incorrect: “… handmade by a single individual.”
    • In fact, several craftspeople have been involved to date in the design, assembly, and software authoring required to build Oscilloclocks. (Even excluding the PCB and case manufacturing processes.)
  2. Debatable: “… timekeeping is controlled by an ultra-precise quartz crystal”
    • It’s true that the current revision Oscilloclock Control Board does have an on-board quartz crystal, and this does keep reasonably accurate time if needed…
    • However the preferred mode of operation is to synchronise time against GPS (using a GPS receiver) or an NTP server (with onboard Wi-Fi or the Oscilloclock Wave).
  3. Debatable: “… the clock can be set to display … temperature”
    • The current revision Control Board and firmware do not support temperature sensing.
    • But it’s true that it’s on the ever-growing list of things to do! Did ChatGPT predict this?

Oscilloclock Bare(ly) makes it to Brazil

Posted on by

Whether directly or indirectly, the pandemic seems to have slowed everything down: chip production; the global economy; and even Oscilloclock blog post publishing!

But perhaps most impacted of all is transport logistics. [Dante] in Brazil discovered this to his dismay in July 2020, when he purchased an Oscilloclock Bare unit. The P.O. had stopped all air service to Brazil just 3 weeks earlier – well after our discussions had started. Oh no!

[Dante]’s crisp new Oscilloclock Bare, ready to go, but unable to ship!

[Dante] waited patiently for 6 months for the post office to resume accepting airmail service to Brazil. But they never did. And FedEx and DHL came at too hefty a price. In desperation, he authorized shipment by sea – and at last, in December 2020, his package was off!

Absence (of air mail service) makes the heart grow fonder...

After an agonizingly long wait, [Dante] finally received his unit 6 months later – in July 2021. He then spent the next 5 months completing his dream project!

[Dante]’s Dream: A Hewlett Packard retrofit

The Oscilloclock Bare is designed to be a no-frills controller assembly that highly knowledgeable folks can install into their own displays. [Dante]’s dream was to use this to convert his beloved HP 182T / HP 8755C unit into a living, breathing scope clock.

And convert he did!

Question: How do you add ambience to a home?
Answer: Instill new life into a device from yesteryear!

Clearly, [Dante]’s 18 month end-to-end was worth the wait.

The Build

[Dante] was kind enough to supply a write-up of his project, including some clever solutions for pitfalls along the way. Let’s hear from him in (mostly) his own words!

Motivation

The model HP 182T is an oscilloscope featuring a large CRT with a graticule of 8 x 10 major divisions and a display area of 133 cm2, coated with a P39 aluminized phosphor for high brightness and long persistence.

The HP 182T works as a display mainframe supporting other HP plug-in test equipment, such as the HP 8755C, a swept amplitude analyzer.

Both items are nowadays considered “vintage” test equipment. But with the Oscilloclock board installed, they have been transformed into a unique appliance with a natural appeal for practical use. Far better than the regular surplus market destinations, or — even worse — destructive disposal!

HP 182T + HP 8755C. Can you spot the Oscilloclock control board?
Control board installed!

HP 8755C in short

This plug-in unit works primarily as a signal conditioner and a multiplexer for “almost dc levels” from three RF detector probes attached to three input independent channels. There are front panel adjustments for the scaling, gain and multiplexing controls that provide the appropriate Y-Axis composite signal for displaying by the HP 182T mainframe.

The Oscilloclock control board was elected to be installed inside this plug-in unit.

HP 182T in short

This oscilloscope is built around the CRT with its high voltage power supply.

The X-Axis signal from the Oscilloclock board is fed to the HP 182T’s chain of the horizontal pre-amp plus output amplifier, which drives the CRT horizontal deflection plates.

The internal wiring of the HP 182T connects the CRT’s vertical deflection plates directly to the plug-in cabinet of the display mainframe, so the Y-Axis signal from the Oscilloclock board is routed inside the HP 8755C itself.

The Z-Axis signal from the Oscilloclock board is fed to the HP 182T’s gate amplifier.

Wires, wires…. What goes where?

Drawbacks

Contrary to any standard X-Y scope where the two input channels are always supposed to have electrically similar (if not identical) characteristics, the correct operation of the Oscilloclock board for the application here was shown to be not as seamless as first imagined. You have to face some details of these integrated “host” equipment (HP 182T + HP 8755C) to see why…

As described, there are distinct amplification chains accepting the Oscilloclock output signals. This presents specific challenges regarding (a) the differential gain for the X and Y signals, and (b) the differential time delay between any combination of the three X, Y, and Z signal outputs of the Oscilloclock board.

First Approach

Before having the board at hand and expecting to make it work as soon it arrived (the shipping took longer than expected due to COVID restrictions), I first planned the signal flow and did the wiring. I had one eye on achieving a ‘clean packaging’ of the board inside the HP 8755C, and the other on ensuring compatibility between the Oscilloclock’s X-Y-Z output signals and their respective chains planned in the host equipment, considering signal amplitude and required frequency response.

The adaptations made at this time considered a minimally-invasive approach, where the criteria was to “make it simple”. This was limited to just opening or re-using connections and keeping the existing routing, in order to use the Oscilloclock’s X-Y-Z output signals in the most simplistic way possible.

Another necessary one-time adaptation was for the board’s power supply, and integration of its PSON output signal with the equipment’s hardware. This part of the design was successfully kept to the end of the project without any further modification.

First time installation of the oscilloclock board

Upon arrival and a bench test of the Oscilloclock board with a scope, I immediately figured out that the amplitude levels for the X and Y output signals were lower than expected (maybe due to my misinterpretation of the specs). I did the gain compensation corrections again and went thru the complete installation of the board inside the host equipment, anxious to see it working.

What a disappointment when instead, up came a completely distorted and elliptically shaped image, blurred with noise, and what looked like un-blanked retrace lines. Worse yet, mainly when alphabetic characters were displayed on the screen, none of the shapes were correctly formed.

Of course, that was time for a break — and a complete review of the job and the work done so far!

Chasing the problems

The Lissajous figures generated by the Oscilloclock board use an approximately 40 KHz  sinusoidal signal, so I started to play with an external generator at the same frequency and amplitude for the X and Y signals (at about 1 Vpp) and trace it inside the HP 8755C and HP 182T.

At this time, I’d already exercised the Z-axis waveform from the Oscilloclock board and the expected processing through the HP 182T. There was no evidence of problems with this Z-axis signal chain, and I achieved a measured propagation delay of around 50 nS.

The minimalist approach mentioned earlier showed its consequences, when a propagation delay of an impressive 8 uS was measured at the vertical deflection plates, and  around 1.5 uS at the horizontal deflection plates! It was time again for another break, to elaborate a new routing scheme for the X and Y signals.

Final Approach

From the previous analysis, I ended up with two different and both very large propagation delays for each of the X and Y signals (as compared with the measured 50 nS for the Z-axis). How to solve this? It did not seem to be only a routing problem.

I decided to investigate X-Y-Z signal propagation delays in the two units separately. After a thorough measurement of propagation delays inside the HP 182T itself, comparing with the HP 8755C plug-in itself (where the Oscilloclock board was installed), I concluded on two countermeasures:

1. The complete removal of the Processor board XA-6 from the HP 8755C. (This is where the Y-axis signal from the Oscilloclock board had initially been connected.) Instead, this routing was transferred directly into the Normalizer Interface board XA-11 (which interfaces with the HP 182T).

2. Also at the Normalizer Interface board XA-11 inside the HP 8755C, the substitution of two original op amps U9A and U9B (HP #1826-0092) by TL072 op amps, which are faster and have a higher slew rate.

These solutions were enough to align the signal propagation and complete my project!

Dante JS Conti, 8 November 2021

Like what you see?

We do! We love to hear back from Oscilloclock owners, to hear their stories.

Check out our previous posts and the Gallery for info on other unique creations!

Screens & Things

Posted on by

Recently I had an enquiry from [Frank], who had just begun a life-long love affair with scope clocks by purchasing one on eBay. The clock was great – but he felt that the two available screens (simple analogue and digital clock faces) lacked a certain oomph.

He then stumbled across Oscilloclock.com, and in his smitten state immediately reached out with his number one question: just what screens are available on an Oscilloclock?

Well, let me save Frank’s time trawling through years of blog posts. Right here in one place are most of the Oscilloclock screens and features created to date.

Enjoy the show!

Standard Time Screens

These stock-standard analogue and digital time screens may be quite simple, but they do evoke the ‘retro’ look that most people appreciate.

Oscilloclock Model 1-S at Tokyo Maker Faire 2013
Heathkit OR-1 Oscilloclock

And you can flip a menu setting to display days, months, years in Japanese:

There are also some ‘random’ screens that add in a bit of dynamic visual entertainment:

  • Random number screen
  • Random letter sequence screen
  • Random four letter word screen (clean words only, by default!)
  • Random phrase screen (the phrase list is typically customized to a theme)

And of course the mesmerizing Timedrops screen:

Themed Screens and Features

… These themed features were developed more recently, and can be added for a small fee to help cover development costs!

Astroclock (Sidereal Time)

External XY input

OscilloTerm (serial terminal)

Oscilloblock (lego)

Metropolis

Aftershock Clock (Earthquake display)

Unbirthday Clock

War Games

Logo screens

Over the years many folks have requested that I render custom logos in Circle Graphics. Here are some examples:

Toshiba ST-1248D - Brass bezel

“Seasonal Treats”

Up next are some fun, mildly interactive animation features. Not exactly screens per se, these animations pop up after a predefined period of inactivity – but only during certain months of the year. Can you guess which months?

Boo!
Santa in your Clock!

Menu screens

There are far too many configuration menu and test screens to present here. Fiddle to your heart’s content!

Various arcs that can be made by blanking out circles

Q. How are screens switched?

Screens are switched simply by rotating the control knob in one direction or other.

There is also a configurable auto-switch feature; the screen is changed every 90 seconds in a predefined order (with the exception of some animation screens). The display time is configurable, and the auto-switch feature can also be turned off for those who prefer to switch screens manually.

Q. How are screens selected & configured?

Customers can request screens to include and/or specify the switching order. The configuration is done here in the lab before clocks are delivered.

Oscilloclock also provides a firmware upgrade kit, which allows the customer to upload a revised version of the firmware into the clock themselves. Using this, updates to screens and other features can be uploaded without shipping the clock back to the lab.

Q. What is the process for rendering a custom screen or logo?

We typically prepare a mock-up based on the customer’s description, sketch, or image file. This is tweaked as needed until the screen looks just right to the customer.

Like what you see? Contact me!

Connect !!

Posted on by

These days, just about everyone has an old oscilloscope lying around. You know, an old, dusty, derelict scope handed down from Grandpa (or Grandma). Well, [Paul] had something even better – an old Tektronix 602 X-Y Monitor! Could an Oscilloclock Control Board drive this vintage beauty? Absolutely. Could I make an aesthetically pleasing case? Definitely. How about time sync via WiFi? Stock standard!

Presenting the Oscilloclock Connect:

Here’s what it looks like plugged in to my fabulous old Tektronix 620 monitor:

And why not have a pair of Connects drive a Tek 601 and 602?

The Build

The main component of the Connect is, of course, a standard Oscilloclock Control Board. As usual, all 121 parts on Paul’s board were individually mounted and soldered by hand. The board then was programmed and underwent rigorous inspection and testing. Finally, the board was cleaned to remove flux and renegade flecks of solder, and sprayed with HV coating for humidity protection and – arguably more importantly – to give it its glorious sheen.

The case was custom-made and professionally machined right here in Japan from 6mm-thick sheets of pure cast acrylic (not extruded). This is an extremely transparent, hard, high grade acrylic – and Oscilloclocks deserve nothing less!

The case was sprayed with a special acrylic cleaner and static protection solution, before fitting the various components. Naturally, every part was cherry-picked, right down to the three BNC connectors – they needed an aesthetically pleasing colour, but they also had to have a shaft long enough to mount through 6mm-thick acrylic!

Finally, the physical interface! The knob was chosen for its perfect finger-fit and delicate aluminium/black tones, which gently contrast with the rest of the unit.

The Compatibility Crisis

Over the years, many folks have observed that the scope at hand has an “X-Y mode”, and asked if they could just ‘plug in’ an Oscilloclock Control Board. “Is it compatible?” Unfortunately, the response has usually been disappointing.

You see, creating figures and characters with Circle Graphics relies on the scope’s ability to turn the beam on and off at split-second intervals. This feature is called a “Z-axis input”. While many scopes from the 80’s and beyond do sport such an input, there are two common limitations:

Limitation 1: AC-coupled Z-axis inputs

Capacitive coupling – effective at isolating the input from cathode potential (-1260V !)

The input is connected to the CRT’s grid or cathode circuit via a capacitor. This is a low-cost, effective way to isolate the (usually) very high negative voltage of the grid circuit from the input.

The problem here is that the capacitor, by its very nature, removes the edges from the pulse. The controller is no longer able to control the beam on/off timing, and you end up with uneven blanking across the segments, as shown in the screenshot at right.

fff

Depending on the values of the capacitor and the surrounding resistors, the symptoms may not be severe. However, the best way to resolve this problem (while still keeping the oscilloscope’s original circuit intact) is to insert an isolated DC blanking amplifier directly in series with the grid (or cathode). See the Kikusui 537 Oscilloclock for an example of this.

LIMITATION 2: INSUFFICIENT BLANKING AMPLIFICATION

Most oscilloscopes tend to require at least +5V on the Z-axis input to noticeably blank the beam. The Connect, however, is only capable of delivering +2.5V. It works just fine if you set the scope’s Intensity control very low, but as you increase intensity, the blanking quickly becomes ineffective.

Below we have a beautiful Japanese YEW (Yokogawa Electric Works) 3667 storage scope. The left shot is misleading due to the camera exposure; the displayed image is actually extremely dim. The right shot shows the same* image with the intensity control increased – the image is bright, but there is no blanking!

* Astute readers will observe that the time is significantly different between the two shots. This is a result of the WiFi NTP sync kicking in right in the middle! More (or less) astute readers may also notice that the scope’s trace rotation is not adjusted very well…

Of course, it would be a simple matter to incorporate a pre-amplifier for the Z-axis, which would solve this problem. This will be introduced with the next Control Board revision!

Like what you see?

Nothing brings more joy than connecting this bundle of usefulness into a woefully unused old oscilloscope or X-Y monitor. If this is of interest to you, visit the Availability page for more information, and of course see the Gallery for other unique creations!

War Games on an Oscilloclock!

Posted on by

As I’ve hinted before, your friendly Oscilloclock gang is entirely pacifistic. We abhor the thought of actual military activity in this modern day and age. BUT we love games just as much as anyone – and we also love light-hearted movies with happy endings!

So when [Ian] (of Bunker Club Clock fame) came up with the idea of a feature based on the iconic 1984 flick “War Games“, I pounced on the chance!

Check out my YouTube channel to see this and other videos in HD!

Now, this may look like a simple animation. But Ian’s Oscilloclock is powered by a tiny processor with minimal specifications, and 100% of the code is written in assembly language. Implementing this baby in assembly and keeping within just 3K of RAM was quite an accomplishment!!

About the host clock

The gorgeous model shown here is a painstakingly-retrofitted Heathkit CO-1015 Engine Analyzer. It’s the perfect play-toy for any serious motor-head who grew up during the Cold War!

First up on the custom build list is the original meter fitted with amber LED lighting and ticking audibly each second. (And yes, the tick intensity can be easily adjusted.)

Next up, there is the optional External X-Y input feature. Normally, this is used for plain and simple Lissajous figures like the below…

… but by tweaking some settings, we can get some segments of Jerobeam Fenderson’s incredible Oscilloscope Music Kickstarter video to display quite nicely!

Peeking inside the Engine Analyzer Oscilloclock is also a must-do! Not only is this visually appealing, but you also get a significant olfactory kick from the sweet smell of vintage electronic components…

Attractive Oscilloclock boards and cabling, neatly tucked away

The original circuit is completely bypassed – but still looks awesome!

Tech Talk – Strategies, Maps, and Missiles

The War Games feature uses the Oscilloclock’s Sprite Engine module to display the world map and up to 9 missiles when the W.O.P.R. system is simulating various war strategies.

32 of the 130+ strategies seen in the movie are implemented. For each strategy, a random number of missiles are launched along a predefined Primary trajectory, followed by a random number of missiles along a predefined Retaliatory trajectory. If any of the 9 missiles remain, they are launched along randomly selected (but predefined) trajectories.

Trajectories are predefined because computing them using 8-bit arithmetic would consume a huge number of cycles! At least, a small amount of randomness is added to the launch position and velocity parameters at run-time, to make things more interesting.

As the simulation progresses through the strategies, the speed of the launches increases and the delay between launches decreases. This gives a similar effect to that in the move, where WOPR moves through strategies at warp speed until it realises that there is no winning this game…

A Joint Effort

Creating a huge number of realistic trajectories (68 in total), translating start and end X and Y coordinates from latitude and longitude into the Oscilloclock’s Cartesian plane was a task of mind-blowing proportions! Here we see our 2nd junior technician eagerly earning his room and board.

Like what you see?

Are you a petrol-head? You need an Engine Analyzer ticking over at your bedside or in your office! Were you brought up during the Cold War, perhaps in the Soviet Union or in the US? Get the War Games feature and fry the world safely! Contact me if you like what you see.

(Disclaimer: Oscilloclock.com hopes that no-one is offended by the deliberately light-hearted tone of this post, in referring to the decidedly serious topic of nuclear warfare.)

Bunker Club Clock

Posted on by

It’s the 1970’s. The cold war. The U.S. and Russia aim nuclear weapons at each other. How do you prepare for the worst? Why, you build a bunker, of course!

Today, [Ian] has done just that. Not a real nuclear fallout shelter, of course, but a period-themed bar called the Bunker Club. What better way to face disaster, than over drinks with the mates!

Ian decided to pepper his bar with vintage equipment that looked the part. But he wanted to make them truly functional, to entertain his retro-loving customers. So, he commissioned the Bunker Club VectorClock!

Now, regular followers of the blog will easily recognize the base unit here as a Tektronix 520A Vectorscope. So far a total of four of these delightfully-lighted machines have been converted to retro Oscilloclocks – see the Gallery for other examples.

But as always with any model, Ian wanted to make some cool customizations. Let’s look at two of them.

1. External XY Input

First introduced in the Metropolis Clock, this feature allows Ian to input two signals and visualize them in X-Y format on the screen. This is very, very useful for generating custom Lissajous figures externally – using either a cheap signal generator, or even an iPhone!

Lissajous figures from an iPhone!

Cool Lissajous figures – even from a humble iPhone! (note, this picture is of the Metropolis Clock)

The external signals are rendered within a rectangular ‘window’, pre-configured to look nice alongside other standard parts of the Oscilloclock screens. For some screens, the window is drawn large but with a lower intensity, forming a kind of ‘watermark’. This is an awesome effect!

2. Custom Logos

Nearly all Oscilloclocks feature some kind of customized logo. Past examples include the customers’ business’ name, the name of the oscilloscope manufacturer, or even the name of the customer’s favourite film:

Toshiba ST-1248D - Brass bezel

Kikusui 537

Metropolis Clock

In Ian’s case, the obvious candidate was his new bar’s official logo – a very chunky-looking rocket blasting through the atmosphere!

Further enhancements … on the way

It seems Ian enjoyed his first clock so much, that he has commissioned a second, with a completely different physical look. Some further special effects and display animation are planned, to further enhance the nuclear theme and keep his customers happy. Stay tuned!

Like what you see?

Do you own a bar? Well, normally you wouldn’t want a clock in your premises, as it would help customers keep track of their time, which would be bad for business. But Oscilloclocks are so much more than timekeepers! Recent feature additions make them lots of fun to watch and fiddle with. If you have special ideas, let me know!

(Disclaimer: Oscilloclock.com hopes that no-one is offended by the deliberately light-hearted tone of this post, in referring to the decidedly serious topic of nuclear warfare.)

Metropolis Mania!

Posted on by

Oscilloclocks are special. Oscilloclocks are unique. We know this. But in November 2015, a request for something exceptionally special and unique arrived from [Andrew] – he wanted me to craft a Metropolis movie themed timepiece!

Metropolis Movie PosterMetropolis is a classic science-fiction silent movie created by Fritz Lang in 1927. It’s an amazingly beautiful film with a fascinating plot, passionate acting, and attractive futuristic props and architecture heavily influenced by the Art Deco and other artistic movements. (Haven’t seen this movie? I recommend “The Complete Metropolis”, Blu-Ray version!)

Well, Andrew was building a very large space at his home dedicated to the Metropolis movie. It would be a full-on “man cave”, with a lounge/bar, music and video venue, mad scientist lab, and collection display space. The mad scientist part of the building would house various scientific demonstrations based on vintage physics or chemistry experiments, with a dose of mad science thrown in.

Andrew was collecting themed art and memorabilia for his man-cave, and had even commissioned a full size ‘Maria’ robot (#3 in the world) from the licensed manufacturer…

But there was one thing missing – a Metropolis 10-hour clock.

Metropolis Time

In the Metropolis movie, the Rulers enjoy their lives in normal time, but the Workers are forced to perform their heavy-labour duties in 2 shifts of 10 ‘worker hours’ each day. The Workers’ clocks are thus labelled with only 10 hours.

Metropolis clocks for Rulers and Workers

Metropolis clocks – Normal time for Rulers (top), but 10-hour time for Workers (bottom)

The 10-hour clock features in multiple scenes throughout the movie, as clear symbology that the controlling and oppressive Masters can even manipulate Time – if only on the surface!

In this scene, Freder struggles with the clock machine...

In this scene, Freder struggles with the clock machine…

[Andrew] wanted to commission an Oscilloclock that would display an authentic 10-hour Worker clock face with accurate hour, second and minute hand movement, as well as the normal 12 (24) hour Ruler clock faces. He also wanted all numerals and characters rendered in the Metropolis font. This could be THE talking piece of the man-cave!

Presenting… the Metropolis Oscilloclock!

After 8 months of discussion and development, the first Metropolis Clock was finally delivered. This unit is based on the same beautiful Toshiba ST-1248D vintage oscilloscope model used in a previous conversion. However, it incorporates some wonderful new features, including LED-backlit valves and an external input feature to support Lissajous figures generated by an iPhone or other device!

The Metropolis Clock - Toshiba ST-1248D - 01

Metropolis Clock - 06

Artwork on the splash screen evokes an image of the skyscrapers in the movie poster…

The clock keeps both 'normal' and Metropolis 10-hour time!

The clock keeps both ‘normal’ and Metropolis 10-hour time!

Realistic LED backlighting - enjoy the valves without actually heating them up!

Realistic LED backlighting – enjoy the valves without actually heating them up!

To be continued…

Each of the new features built out for this exotic creation deserves a post on its own. Stay tuned for many more pictures and information about Lissajous inputs, backlit valves, and Metropolis time switching!

Also, careful readers would notice my use of the phrase “first Metropolis Oscilloclock”. Andrew was so delighted with the Toshiba ST-1248D unit that he commissioned a second Metropolis clock with even more firmware enhancements, based on the Tektronix 520A. Another topic for another day!

See the Metropolis Archive for all other posts in this series!

Like what you see?

Metropolis is just fantastic as a theme for a custom Oscilloclock. But if you have a different passion that needs horological augmentation, let me know!

Kikusui Time

Posted on by

Time – the universal constant. Time passes the same for all peoples; rich or poor, busy or idle, inspired or dispirited. And time has certainly passed for Oscilloclock.com since the 2015 Tokyo Maker Faire – the event that just keeps giving!

At last, we present the final model from that Faire – the Kikusui 537 Oscilloclock!

Kikusui 537 Oscilloclock

See this in HD, and find more exciting videos on my YouTube channel

The Kikusui 537 was hand-picked for conversion by the lab’s youngest technician (9 at the time). He chose it for its small size and portability, but also for its cute colour scheme! A dainty red sweep adjustment knob highlights a bright white and black control panel, with a blue case providing overall contrast and visual soothing.

Kikusui 537 Oscilloclock

The 537 Oscilloclock’s small size makes it the perfect clock for an office desk, bedside table, or mantle. And since this is a ‘maximum re-use’ conversion, the existing circuit is active and all the front panel controls are fully functional. Fiddle with the image’s size and position to your heart’s content! Switch from XY mode to normal sweep mode, to view raw Oscilloclock signals in real time, as the seconds tick by!

History

The 537 was manufactured by Kikusui Electronics Corp., a major producer of test equipment in Japan since 1951. It was produced in large numbers from 1975 and was extremely popular for its small form factor, solid-state design, 5 MHz bandwidth, and ‘low’ price of 45,000 yen (perhaps USD 1,000 in today’s terms). See the catalogue page (Japanese only) and the operating manual (Japanese and English).

Kikusui Logo

The Kikusui Electronics Corp. logo

Construction highlights

In a previous post, I mentioned there are several general approaches to converting an oscilloscope. Since the Kikusui 537 is fully solid-state (it uses transistors instead of valves/tubes, except for the CRT) and it is only 40 years old, I decided on the maximum re-use, minimal invasion approach. (I really should trademark that term!)

This approach involves tying the Oscilloclock Control Board‘s outputs directly into the existing X and Y amplifier circuits. This was easy to do in the 537!

Kikusui 537 Oscilloclock - inside top

Oscilloclock Control Board mounted in the 537

However, as discussed in the Circle Graphics post, we also need to be able to blank the beam at extremely precise intervals. Sadly, the 537 (like nearly all oscilloscopes of this vintage) does NOT have a convenient DC pulse-tolerant Z-axis input. I therefore installed an Oscilloclock Power Board, partially populated to serve as an isolated blanking amplifier, in series with the grid.

Partially populated Oscilloclock Power Board

Partially populated Oscilloclock Power Board

Finally, an Oscilloclock Supply Board was needed to power the other boards.

An Oscilloclock Supply Board is also nestled in there!

An Oscilloclock Supply Board is also nestled in there!

Mounting the Control

What better place to fit the rotary encoder, than on the beautiful red sweep frequency adjustment knob that my junior technician liked so much! Here’s the general story:

Kikusui 537 Oscilloclock - control (original)

Sweep adjust control in its original state

After removing the potentiometer

After removing the potentiometer

The encoder, after hacking with a hacksaw!

The encoder, after hacking with a hacksaw!

Kikusui 537 Oscilloclock - control mounted

Voila – sweep knob now drives the rotary encoder!

Like what you see?

One of the two Kikusui 537 Oscilloclocks crafted for the Maker Faire is still available for the special person with a soft spot for a krazy kikusui klock. Visit the Availability page for more information, and of course see the Gallery for other unique creations!

Timedrops in Spring

Posted on by

Spring… a beautiful time of year! I particularly enjoy the warm rains, with the soothing effects of raindrops pit-pattering into puddles outside my window.

But no longer do I need to look outside! Inspired by a recent post on Hackaday, a suggestion from [A-Nonamus] in the neonixie-l group, and by Spring itself, I can now enjoy Timedrops on my Oscilloclocks:

See this in HD, and find more exciting videos on my YouTube channel
Music credits: Space Bazooka by Kirkoid (c) 2013 Licensed under a Creative Commons Attribution (3.0) license. http://dig.ccmixter.org/files/Kirkoid/43005

Assembly?!

The current Oscilloclock firmware is written entirely in PIC 18F Assembly. The Timedrops feature leverages a Sprite Engine module, first developed for Halloween Seasonal Treats and later utilized in the Santa’s sleigh feature.

A sprite engine

A sprite engine

To display Timedrops, the sprite engine is initialized with 10 sprites – 4 digits for hours and minutes, a colon, and 5 ellipses as ‘ripples’. The 5 characters are set at the top of the screen with a randomized negative velocity. When a character reaches the bottom boundary, the sprite engine’s default explode sequence is started, and the associated ripple sprite is made visible and set to expand. When the explosion sequence for a character sprite is complete, the sprite is reset at the top of the screen.

Looking for the source code? Sorry – refactoring is still under way, and the latest revision with the Timedrops feature will be uploaded in the near future.

The Oscilloclock Core

Posted on by

Over the years, folks out there have reached out to me with all sorts of crazy ideas about cases and housings for scope clocks and custom CRT displays. Here are some interesting examples:

  • The console of a vintage pipe organ
  • An ancient grandfather clock
  • A cylindrical case made of some exotic wood
  • A “cathedral” style vintage radio

Essentially, these people wanted just the innards of an Oscilloclock, which they would build into their own case. Could I help out?

Absolutely! For people who want to roll their own cases, and who have experience handling high voltage electronics and CRTs, I occasionally prepare custom board sets that are lovingly hand-assembled, tested, and tweaked for optimum performance with a given CRT. Here we go:

The Oscilloclock Core

Oscilloclock Core, hand-crafted in 2015 for a discerning customer in Germany

An Oscilloclock Core, hand-crafted in 2015 for a discerning customer in Germany


The standard Oscilloclock Core layout, on a test acrylic mounting

The standard Oscilloclock Core layout, on a test acrylic mounting

I supplied this particular unit with an 8SJ42J Chinese-made CRT, just for testing purposes. This is a 3″ PDA tube with a highly restrictive rectangular viewing area, but the customer found it just great for checking things out!

Oscilloclock Core - complete set for 8SJ42J - 03Oscilloclock Core - complete set for 8SJ42J - 06
Oscilloclock Core - complete set for 8SJ42J - 02

What comes with it?

Here’s what’s comprises the typical Oscilloclock Core:

  • 1 x Fully assembled and programmed Control Board (optional on-board GPS)
  • 1 x Fully assembled Deflection Board (latest ultra-linear revision)
  • 1 x Fully assembled Power Board optimised for a given CRT (latest revision with options: onboard high-bandwidth blanking amplifier, rotation coil supply, auto fan speed control, unblanking plate modulation, and isolated bright/dim input)
  • 1 x Fully assembled CRT Board (optional; an external blanking amplifier recommended when the CRT cable is longer than 50cm)
  • 1 x Rotary encoder
  • 1 x Worldwide 9V power supply (high quality wall wort unit, commercial ratings)
  • 1 x Garmin GPS unit with 5m cable; wired to board-side connector (not required for onboard GPS)
  • 1 x Set of standard inter-board and CRT harnesses for testing and reference (10kV/3kV silicone melt-proof used for HV cables, other LV cabling also heat-resistant)
  • 1 x Cast acrylic test mounting assembly, fitted with the boards, ready for testing out-of-the-box with your CRT
  • 1 x Ceramic adjustment screwdriver
  • Service documentation (schematics, board layouts, complete Digikey BOMs, harness specs)
  • All components are latest available types sourced within the last 6 months, 0.1% or 1% tolerance resistors, minimum 2 x rated working voltage capacitors, all lovingly hand-mounted by myself
  • All boards sprayed with HV lacquer for moisture and arcing protection
  • 2-week satisfaction guarantee. But no long-term warranty on board-only purchases

Naturally, the lengths of all harnesses and inter-board cabling can be customized according to the owner’s requirements. And there is also an Oscilloclock Core Cube arrangement, where the boards are stacked to reduce the length and width of the overall unit.

What CRTs does it support?

The Power Board and Deflection Board are increasingly flexible with each revision, but I insist on performing all configuration of the Core here in my lab. This allows me to tweak for maximum performance, and provide a proper satisfaction guarantee.

Typically I work with the owner to recommend a CRT based on preferences such as size, colour, and aesthetics. However in cases where the owner already has a CRT in mind, and I don’t have the particular CRT or a close equivalent, I ask the owner to send me one to test against. Or, I simply procure one; after all, one can never have too many CRTs!  (Though my better half does not agree…)

The current Oscilloclock Core board revisions meet the following operating parameters:

  • Maximum cathode to deflection voltage of 2175V
  • Maximum accelerator voltage of 3525V for PDA type CRTs
  • 6.3V heater, max 0.7A
  • Support for “Deflection Blanking” CRTs (see treatise here)
  • CRT rotation coil supply (+/-5V)
  • Precision deflection amplifier capable of driving +/- 275V with 0.1% linearity

Like what you see?

Check out the Availability page for more information, and of course see the Gallery for some unique CRT creations – many with an Oscilloclock Core at their heart!
